Tropical Hardwood Technical Data Sheets
Technical data sheets (TDS) for Ipe, Cumaru, Tigerwood, Garapa, and Massaranduba wood. Janka hardness, density, MOE/MOR, shrinkage rates, fire ratings, and downloadable span charts — built for architects, engineers, and contractors who need the numbers.
Density
Weight per cubic foot. Higher density = harder, more durable wood.
MOE / MOR
Modulus of Elasticity (stiffness) and Modulus of Rupture (breaking strength).
Janka Hardness
Force required to embed a steel ball into the wood. Industry standard for hardness.
Fire Rating
ASTM E84 flame spread classification. Class A is the highest rating for building materials.
Wood Species Technical Data — Properties & Specifications
Mechanical and physical properties from each species' technical data sheet. Values are published averages based on standard test conditions (ASTM, USDA FPL) and may vary by individual board.
Ipe Technical Data Sheet
Handroanthus spp. — also known as Brazilian Walnut, Lapacho
69 lbs/cu ft (1,010 kg/m³)
3,510 lbf
3,140,000 psi
25,400 psi
5.9% / 7.2%
Class A (ASTM E84)
Cumaru Technical Data Sheet
Dipteryx odorata — also known as Brazilian Teak
66 lbs/cu ft (1,070 kg/m³)
3,540 lbf
2,830,000 psi
22,800 psi
5.4% / 8.0%
Class A (ASTM E84)*
Tigerwood Technical Data Sheet
Astronium graveolens — also known as Goncalo Alves, Muiracatiara
60 lbs/cu ft (960 kg/m³)
2,170 lbf
2,470,000 psi
19,700 psi
5.2% / 7.6%
Not independently tested†
Garapa Technical Data Sheet
Apuleia leiocarpa — also known as Brazilian Ash
52 lbs/cu ft (830 kg/m³)
1,620 lbf
2,160,000 psi
16,900 psi
4.5% / 7.5%
Not independently tested†
Massaranduba Technical Data Sheet
Manilkara bidentata — also known as Brazilian Redwood, Bulletwood
69 lbs/cu ft (1,100 kg/m³)
3,190 lbf
2,790,000 psi
23,100 psi
6.2% / 8.5%
Not independently tested†
Fire Rating & Building Code Notes
Ipe has been independently tested under ASTM E84 and has achieved a Class A flame spread rating (flame spread index ≤ 25), which is the highest classification for building materials — comparable to steel and concrete. This makes Ipe one of the only natural woods that can meet WUI (Wildland-Urban Interface) code requirements in many jurisdictions without chemical treatment.
Cumaru has also achieved Class A results in independent third-party ASTM E84 testing, though results may vary by specific sample and test conditions. Check with your local building department for accepted test reports.
† Species marked as "Not independently tested" have not undergone ASTM E84 testing to our knowledge. This does not mean they are unsafe — only that no standardized fire test data is currently published for these species. Always verify local code requirements and consult your Authority Having Jurisdiction (AHJ) before specifying any material for fire-rated assemblies.
Fire performance can be influenced by board thickness, installation method, finish coatings, and environmental conditions. Ipe Woods USA does not guarantee any specific fire rating for any product. Consult a fire protection engineer for project-specific requirements.
Downloadable Span Charts & Technical Data Sheet PDFs
Structural span tables and technical data sheets by species and board size. Print-ready PDFs for the field, plan sets, or building department submittals.
All Species Span Charts
Combined span tables for Ipe, Cumaru, Tigerwood, Garapa, and Massaranduba — side-by-side comparison across all board sizes.
Ipe Span Chart & Structural Reference
Span tables by board thickness (1x4, 1x6, 5/4x6, 2x) with residential deck assumptions and load rating notes for Ipe.
Cumaru Span Chart & Structural Reference
Span tables and structural data for Cumaru (Brazilian Teak) decking by board size and profile.
Tigerwood Span Chart & Structural Reference
Span tables, joist spacing, and load data for Tigerwood (Astronium) decking boards.
Garapa Span Chart & Structural Reference
Span tables and structural reference for Garapa (Brazilian Ash) decking boards.
Massaranduba Span Chart & Structural Reference
Span tables and structural reference for Massaranduba (Brazilian Redwood) decking boards.
Important Disclaimer
Technical Data: The mechanical and physical property values listed on this page are published industry averages compiled from sources including the USDA Forest Products Laboratory, academic research, and third-party testing reports. Individual boards may vary significantly based on growth conditions, moisture content, grain orientation, and other natural factors. These values are provided for general reference only and should not be used as the sole basis for structural engineering calculations.
Fire Ratings: Fire test results referenced on this page are based on specific third-party ASTM E84 tests conducted on specific samples under controlled conditions. Fire performance in real-world installations may differ due to board thickness, installation method, coatings, and environmental factors. Ipe Woods USA does not certify, warrant, or guarantee any specific fire rating for any product sold. Always consult your local Authority Having Jurisdiction (AHJ) and a qualified fire protection engineer before specifying materials for fire-rated or WUI applications.
Span Charts & Structural Data: Span charts provided are for general reference based on standard residential deck assumptions. They are not a substitute for engineering calculations by a licensed professional. Always verify compliance with local building codes, IRC requirements, and project-specific load conditions. Ipe Woods USA assumes no liability for design or construction decisions based on these documents.
General: Ipe Woods USA makes no warranties, express or implied, regarding the accuracy, completeness, or fitness for any particular purpose of the information on this page or in the downloadable documents. Use of this information is at the user's own risk. Always engage qualified professionals — including licensed engineers, architects, and contractors — for your specific project requirements.
