5/4x6 Ipe Rainscreen Siding board profile diagram
Siding

5/4x6 Ipe Rainscreen Siding

This 5/4x6 Ipe Rainscreen siding board offers unmatched exterior cladding longevity, backed by Ipe's 3,680 Janka hardness and a natural lifespan of up to 75+ years. The rainscreen profile is designed for ventilated clip systems, allowing airflow behind the cladding for superior moisture management on exterior cladding and accent walls. In stock and ships nationwide — order Ipe siding online or call 1-844-674-4455 for expert guidance.

5/4 x 6(1"×5.5" actual)[25.4mm × 139.7mm]
Contractor Trusted
Expert Backed
Ships Nationwide
SKU: IPE-54X6-RAIN-SB-L1

Configure Your Order

Select profile, grade, and length below to see live pricing

Rainscreen

Select and Better is our standard grade

Length Guide

Available lengths: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22′

Estimated Shipping Weight
Weight per linear foot:2.67 lbs/LF
1' board:3 lbs

5/4x6 Ipe Rainscreen Siding — Complete Guide

Everything you need to know about rainscreen ipe siding

About 5/4x6 Ipe Rainscreen Siding

Ipe lumber is a premier choice for exterior siding and cladding applications, particularly when styled in a rainscreen profile. Known for its exceptional dimensional stability and impressive resistance to weathering, Ipe provides a robust solution for facades that must withstand the elements. The rainscreen profile not only enhances aesthetic appeal, creating distinctive shadow lines, but also allows installation flexibility, accommodating various orientations to achieve the desired architectural effect.

  • Superior dimensional stability reduces warping and splitting in changing climates.
  • Exceptional weather resistance makes Ipe suitable for long-term outdoor use.
  • Rainscreen profile enhances aesthetics with shadow lines and visual depth.
  • Orientation flexibility allows for unique installation designs.

Key Benefits

Exceptional Durability

Ipe exhibits outstanding resistance to rot, insects, and moisture, ensuring longevity in exterior applications.

Aesthetic Versatility

With a beautiful grain pattern and rich color variations, Ipe complements various architectural styles, enhancing visual appeal.

Sustainable Choice

Sourced from responsibly managed forests, Ipe lumber is an eco-friendly option for building sustainable structures.

Technical Specifications

Janka Hardness

3680

Density

approximately 68 lbs/ft³

Durability Rating

Class 1 (highest durability rating)

Dimensional Stability

Highly stable, resistant to warping and splitting under environmental pressures.

Installation Guide

Difficulty:
Moderate

Key Tips:

  • Ensure proper ventilation behind the rainscreen system to allow water to escape.
  • Accommodate for expansion gaps in the installation to prevent buckling.
  • Select appropriate fasteners to avoid moisture entrapment.

Recommended Tools:

Saws (circular or miter) for precise cuts.
Drill for fastening systems.
Level to ensure even installation.

Maintenance & Care

Cleaning

Regularly clean with a mild detergent and water to remove dirt and debris.

Finishing

Periodic application of a UV-blocking finish can enhance color retention and protection against weather.

Weathering

Expect natural weathering to a silver-gray patina over time, with minimal maintenance required for color retention.

Frequently Asked Questions

A 5/4x6 Ipe board weighs approximately 2.67 lbs per linear foot. Ipe has a density of about 69 lbs/ft³, making it one of the densest commercially available hardwoods. Always factor weight into your structural and shipping calculations.

Yes — Ipe is rated Durability Class 1 (Very Durable) and is naturally resistant to rot, decay, insects, and fungal attack without chemical treatment. It is Class A fire-rated and performs exceptionally well in full exterior exposure including siding applications. While ground contact is possible, we recommend elevating Ipe boards at least 6" above grade for maximum lifespan.

Ipe outperforms composite in hardness (3,680 vs ~200 Janka), lifespan (up to 75+ years vs 25-30 years), and heat resistance. Unlike composites, Ipe won't melt, warp in extreme heat, or fade significantly. While initial cost is similar ($8-15/LF installed), Ipe costs less over its much longer lifetime. Composites do offer lower upfront maintenance.

Ipe requires minimal maintenance. Without treatment, it naturally weathers to an elegant silver-gray patina over 6-12 months. To maintain the original warm brown color, apply a UV-inhibiting penetrating oil (like Ipe Oil or Penofin) once or twice annually. Cleaning involves periodic washing with a mild soap solution. No sanding, staining, or sealing is required for structural durability.

Ipe is DIY-friendly with proper preparation. Key requirements: (1) Always pre-drill all screw holes — Ipe is too hard for direct screwing. (2) Use only 305 or 316 stainless steel fasteners — standard hardware will corrode and stain. (3) Face-screw with stainless steel trim-head screws. (4) Allow boards to acclimate on-site for 5-7 days before installation. A compound miter saw with a carbide-tipped blade is recommended.

A nominal 5/4x6 Ipe board has actual finished dimensions of 1" × 5.5" (25.4 x 139.7 mm). The "5/4x6" is the nominal (rough-cut) size — after kiln drying and precision surfacing, all hardwood lumber finishes slightly smaller. This is standard across the lumber industry, similar to how a nominal 2×4 softwood measures 1.5" × 3.5". Always use the actual dimensions (1" × 5.5") when calculating material quantities and coverage for your project.

We responsibly, legally, and ethically source all our Ipe. We work only with suppliers who follow responsible forestry practices with full chain-of-custody transparency. Note: We are not FSC certified. Ipe trees grow naturally in diverse tropical forests and regenerate well under managed harvest. The extremely long lifespan (up to 75+ years) means fewer replacements compared to softwood or composite alternatives, reducing long-term environmental impact.

Shipping & Delivery

Nationwide delivery: We ship to all 50 states via LTL freight, flatbed, or terminal pickup

Typical lead time: 5-10 business days for standard orders (custom milling may add 2-3 weeks)

Shipping estimate: Final freight cost calculated at checkout based on your location and order size

Rush service available: Contact us for expedited milling and shipping options

Alternative Siding Option

This same Ipe 5/4 x 6 is also available in a different siding profile:

Shiplap

Overlapping profile for traditional siding applications
